American standard Type Transformer

Shell Material: Steel Plate
Rated Voltage: 4-24 Kv
Certification: ISO9001:2000, CCC,CE
Form: Partly-welded Type
Rated Capacity: 50 to 3500kVA
Production Capacity: 300pieces/Month

Phase number: three phases

Description

Product Description

Pad Mounted (American type) Transformer 100 to 3000kVA Oil Immersed Prefabricated Substation

Outdoor prefabricated transformer substation. EU or US style. 12kV, 15kV, 24kV, 36kV. Available.
MV RMU equiped, LV can be optional with reactive power compensator or with Harmonic wave filtering.
Outdoor prefabricated transformer substation(Combined Transformer)
Technical Parameters

Name  Unit   MV equipment   Transformer  LV Equipment
 Rated voltage  kV  11~33kV  11~33kV/0.4  0.4
 Rated current  A   630  3/75~150/3750 Less than 4000
 Frequency  Hz    50
 Rated Capacity  kVA  50-2500
 Pfr withstand   kV  42/50/70/95  2.5
  BIL  kV   75/125/170/185
Crust Protection Grade  IP23 Oil type 55; dry type 65 IP23
Noisy Grade  dB
Appearance Dimensions mm According to primacy wiring circuit schema

WORKING CONDITIONS
1. Altitude: no more than 2000M.



2. Ambient temperature: high temperature: +40ºC; Low temperature: -45ºC : high monthly average temperature: +30ºC : high annual average temperature: +20ºC;



3, installation environment: no explosive, corrosive liquid, gas and dust, installation site without violent shock, allowed in a certain period of time Or run completely submerged in water.



4. Ground acceleration induced by earthquake Ag; The horizontal direction is lower than 3m/s; The vertical direction is lower than 1.5m/s.



5, the waveform of the power supply voltage: approximately sine wave.



6, three-phase power supply symmetry: for three-phase underground transformer, three-phase power supply voltage should be roughly symmetrical.

PRODUCTION DETAILS
Pad Mounted (American type) Transformer 100 to 3000kVA Oil Immersed Prefabricated SubstationPad Mounted (American type) Transformer 100 to 3000kVA Oil Immersed Prefabricated Substation
